2 axles LOW BED SEMI TRAILER for vehicles transport

FOB Reference Price:Get Latest Price
US $14,999-24,900 / Unit | 1 Unit/Units (Min. Order)
Supply Ability:
300 Unit/Units per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Use:
Truck Trailer
Type:
Semi-Trailer
Material:
Steel
Certification:
ISO
Size:
13000*3000*,1102mm
OEM No.:
3708322800116
Max Payload:
40T
Place of Origin:
Hubei, China (Mainland)
Brand Name:
VELDLION
Model Number:
VL9330
color:
optional
Packaging & Delivery
Packaging Details
Nude. Ro-ro ship / Bulk transport / Container packing / SKD / etc
Delivery Time
20 working Days

Specifications

2axles LOW BED SEMI TRAILER
1.strong deck design
2.load excavator,big equipment etc
3 CCC,ISO9001
4. we are factory

Fuction of  2 axles LOW BED SEMI TRAILER:



Delivery for Excavator, Machinery, Road Roller, Containers, Groceries, and etc.





Parameters of  2 axles LOW BED SEMI TRAILER





Tare Weight

About 8.5-13T

Dimension

12000mm-18000mm*2500mm-3500mm*3050mm

Please indicate the working platform height and length.

Loading Capacity (T)

30T-100T

Axle

13 T/16T, FUWA /BPW Brand

Rim

6.5-20/7.5-20/8.00-20/8.5-20

Tire

8.25R20/10.00R20/11.00R20/12.00R20

Suspension

Mechanical suspension (Germany Type or America Type)

Or Air suspension (China brand or BPW brand )

Spring leaf

90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12

King pin

JOST brand 2.0 or 3.5inch bolts type or Welding type

Support leg

JOST brand D200T or China brand 28Tons (Double speed)

Main beam

Height: 450mm-520mm, upper plate is 14mm-25mm, middle plate is 8mm-12mm,

down plate is 16mm-25mm ; Material is Q345B Steel .

Side beam

16mm -25mm channel steel ( Material is Q235steel ).

Ladder

Manual or Hydraulic type

Gooseneck

For choose

Brake chamber

WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks

ABS

Optional

Twist Locks

Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)

Valve

WABCO valve

Light

LED light

Voltage

24V

Receptacle

7 ways (7 wire harness)

Tool box

One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint

Shipping Terms:

By bulk cargo carrier, RORO or 40HQ container.





More Information of purchasing 2 axles LOW BED SEMI TRAILER:


1. About our company
HUBEI VELDLION MACHINERY CO., Ltd is an authorized truck manufacturer.

2.  About our trucks
The main product we have is HOWO tipper trucks, A7 tractor trucks, concrete mixer trucks, cargo trucks, dry cement transport truck, fire fighting truck, all-wheel driving wheel, oil/water/fuel tanker truck, mining dump truck, port terminal tractor truck, semi-trailer truck head, special trucks for army and so on.

3. About VELDLION:
Be comprehensive with Euro2 and Euro3 engine equipped.
Driving type: 4×2, 4×4, 6×2, 6×6, ×4, 8×4, 10×4,and etc.
Power range: 266PS - 420PS.

As an old manufacturer, we've exported our products all over the world, especially in Asia, Africa, South America, and also in the Middle East.
